Pine Script v6 Enums Guide

What Are Enums in Pine Script v6

Pine Script v6 introduces enums (enumerations) as a new data type that lets you define a fixed set of named values¹. If you have used enums in other programming languages like Python, TypeScript, or C#, the concept is familiar: instead of passing raw strings or integers around your code, you declare a type with a specific list of allowed values, and the compiler enforces that only those values are used.

Enums solve a real problem in Pine Script development. Before v6, if you wanted a user to choose between three oscillator types, you would use input.string() with an options array of plain strings. Your code would then compare those strings in if or switch blocks, and a single typo would silently break the logic. Enums eliminate that risk entirely. The compiler catches invalid values at compile time, and input.enum() automatically generates dropdown menus from your enum fields².

This guide covers everything you need to know about Pine Script enums: declaring them, using them in inputs and switch statements, storing them in collections, and building practical trading indicators with them.

Declaring Enums

You declare an enum using the enum keyword, followed by the enum name and its fields³. Each field represents one possible value (member) of the enum type. Fields can have optional string titles that provide human-readable descriptions³.

Here is the basic syntax:

[export ]enum <enumName>
    <field_1>[ = <title_1>]
    <field_2>[ = <title_2>]
    ...
    <field_N>[ = <title_N>]

And here is a concrete example declaring a Signal enum with three fields:

//@enum           An enumeration of named signal states.
//@field buy      Represents a "Buy signal" state.
//@field sell     Represents a "Sell signal" state.
//@field neutral  Represents a "neutral" state.
enum Signal
    buy     = "Buy signal"
    sell    = "Sell signal"
    neutral

Several things to note about this declaration:

• The Signal identifier is the enum name, which also serves as the unique type name
• The buy and sell fields have explicit string titles ("Buy signal" and "Sell signal")
• The neutral field has no specified title, so its title defaults to the string representation of its name: "neutral"³
• The //@enum and //@field annotations document the purpose of the enum and its members in the source code³

Documentation Annotations

Pine Script supports special comment annotations for enums that serve as inline documentation:

• //@enum describes the overall purpose of the enum type
• //@field describes what each individual member represents

These annotations are optional but recommended for any enum that other developers will read or that you export from a library.

Using Enum Members

To access a member of an enum, use dot notation on the enum name³:

enumName.fieldName

You can assign enum members to variables, pass them to function parameters, and store them in user-defined type (UDT) fields. The compiler enforces that any variable declared with an enum type can only hold members of that specific enum or na³.

// The compiler infers the type as Signal from the assigned value.
mySignal = Signal.neutral

// Explicit type declaration is required when initializing with na.
Signal myOtherSignal = na

The first line works without a type annotation because the compiler infers the type from Signal.neutral. The second line requires the explicit Signal type keyword because na alone does not tell the compiler which enum type the variable should accept.

Comparison Operators

Enum members support the == and != comparison operators². You can use these comparisons in conditional structures to build clean, type-safe logic:

if mySignal == Signal.buy
    strategy.entry("Long", strategy.long)
else if mySignal == Signal.sell
    strategy.close("Long")

Enum Inputs

The input.enum() function creates a dropdown input in the script's Settings/Inputs tab². The dropdown options are automatically populated from the enum's fields, and the displayed text for each option is the field's title.

Here is the function signature²:

input.enum(defval, title, options, tooltip, inline, group, confirm, display, active) → input enum

And here is a practical example:

//@version=6
indicator("Enum Input Demo")

//@enum An enumeration of oscillator choices.
enum OscType
    rsi = "Relative Strength Index"
    mfi = "Money Flow Index"
    cci = "Commodity Channel Index"

//@variable An enumerator of the OscType enum. Its type is "input OscType".
OscType oscInput = input.enum(OscType.rsi, "Oscillator type")

//@function Calculates one of three oscillators based on a selection value.
calcOscillator(float source, simple int length, OscType selection) =>
    result = switch selection
        OscType.rsi => ta.rsi(source, length)
        OscType.mfi => ta.mfi(source, length)
        OscType.cci => ta.cci(source, length)

plot(calcOscillator(close, 20, selection = oscInput))

The dropdown in the script's settings displays "Relative Strength Index", "Money Flow Index", and "Commodity Channel Index" as the available options. When the user selects an option, the corresponding enum member is assigned to oscInput, and the calcOscillator() function uses a switch statement to determine which technical indicator to calculate.

The selection parameter of calcOscillator() can only accept four possible values: OscType.rsi, OscType.mfi, OscType.cci, or na. Any other value would cause a compilation error³.

Filtering Dropdown Options

The optional options parameter lets you display a subset of enum fields in the dropdown instead of all of them². This is useful when you want to expose only certain options to the user while keeping the full enum available for internal logic.

Switch Statements with Enums

Enums and switch statements are a natural pair. The switch structure maps each enum member to a specific action or calculation, providing clean pattern matching with compile-time safety.

//@version=6
indicator("Enum Switch Demo", overlay = true)

//@enum Signal display mode options.
enum SignalType
    long  = "Only long signals"
    short = "Only short signals"
    both  = "Long and short signals"
    none

SignalType modeInput = input.enum(SignalType.both, "Signal mode")

float rsiValue = ta.rsi(close, 14)
bool longSignal  = ta.crossover(rsiValue, 30)
bool shortSignal = ta.crossunder(rsiValue, 70)

//@variable Whether to show the current signal based on the mode.
bool showLong = switch modeInput
    SignalType.long => longSignal
    SignalType.both => longSignal
    => false

bool showShort = switch modeInput
    SignalType.short => shortSignal
    SignalType.both  => shortSignal
    => false

plotshape(showLong, "Long", shape.triangleup, location.belowbar, color.green)
plotshape(showShort, "Short", shape.triangledown, location.abovebar, color.red)

The switch structure handles each possible value of the SignalType enum. The default branch (=> false) covers any unmatched cases, including na and the none member. This pattern is cleaner and safer than comparing strings, because the compiler will warn you if you reference an enum member that does not exist.

Enums in Collections

Pine Script collections (arrays, matrices, and maps) can store enum members, giving you strict control over the values they contain³.

Arrays of Enum Members

To create an array of enum members, use the enum name in the type template:

enum FooBar
    foo
    bar
    baz

//@variable An array that can only hold FooBar.foo, FooBar.bar, FooBar.baz, or na.
array<FooBar> fooBarArray = array.new<FooBar>()

The array enforces type safety. You cannot push a member of a different enum into this array, even if the field names are identical.

Maps with Enum Keys

Enums are particularly powerful with maps, because unlike other non-fundamental types, scripts can declare maps with enum keys³. This gives you strict control over every possible key in the map.

Here is a map that uses Signal enum members as keys:

var map<Signal, float> signalCounters = map.new<Signal, float>()

This map can contain at most six key-value pairs: one for each of the five Signal fields plus a possible na key. Maps cannot contain duplicate keys, so this structure is inherently bounded and predictable.

Enum Field Titles

Every enum field has a string title. If you provide an explicit title (using = "Title" syntax), that title is used. If you omit it, the title defaults to the string representation of the field name³.

You can retrieve a field's title at runtime using the str.tostring() function². This is the only way to convert an enum member to a string for use in labels, tables, or other display logic.

//@version=6
indicator("Field Titles Demo")

enum Exchange
    BINANCE
    BITSTAMP
    COINBASE
    KRAKEN

enum Pair
    BTCUSD
    ETHUSD
    SOLUSD

Exchange exchangeInput = input.enum(Exchange.BINANCE, "Exchange")
Pair pairInput = input.enum(Pair.BTCUSD, "Pair")

//@variable The exchange:symbol pair built from enum field titles.
simple string symbol = str.tostring(exchangeInput) + ":" + str.tostring(pairInput)

plot(request.security(symbol, timeframe.period, close), "Requested close", color.purple, 3)

In this example, none of the enum fields have explicit titles, so each field's title is its own name (BINANCE, BTCUSD, etc.). The script concatenates the titles to form a valid ticker identifier like "BINANCE:BTCUSD" for the request.security() call.

Important: The str.format() and log.*() functions cannot accept enum members directly². To use a field's title in a formatting function, call str.tostring() on the field first, then pass the resulting string.

Signal State Tracker

This example demonstrates a complete indicator that uses an enum with a map to track and count signal states across all chart bars. It combines many enum features: declaration with titles, switch-based logic, map storage with enum keys, and title retrieval for display.

//@version=6
indicator("Signal State Tracker", overlay = true)

//@enum An enumeration of named signal states.
enum Signal
    strongBuy  = "Strong buy"
    buy        = "Buy"
    neutral    = "Neutral"
    sell       = "Sell"
    strongSell = "Strong sell"

int lengthInput = input.int(50, "Length", 2)

//@variable A map counting the number of bars with each signal state.
var map<Signal, float> signalCounters = map.new<Signal, float>()

//@variable A table displaying signal counts.
var table infoTable = table.new(position.top_right, 1, 1, chart.fg_color)

if barstate.isfirst
    signalCounters.put(Signal.strongBuy, 0)
    signalCounters.put(Signal.buy, 0)
    signalCounters.put(Signal.neutral, 0)
    signalCounters.put(Signal.sell, 0)
    signalCounters.put(Signal.strongSell, 0)
    infoTable.cell(0, 0, text_color = chart.bg_color,
         text_halign = text.align_left, text_size = size.large)

float ema  = ta.ema(close, lengthInput)
float rank = ta.percentrank(close, lengthInput)

//@variable The current signal state based on EMA and percent rank.
Signal signalState = switch
    close > ema => rank > 70 ? Signal.strongBuy : rank > 50 ? Signal.buy : Signal.neutral
    close < ema => rank < 30 ? Signal.strongSell : rank < 50 ? Signal.sell : Signal.neutral
    => Signal.neutral

// Increment the counter for the current signal state.
signalCounters.put(signalState, signalCounters.get(signalState) + 1)

// Display the signal counts on the last bar.
if barstate.islast
    string tableText = ""
    for [state, count] in signalCounters
        tableText += str.tostring(state) + ": " + str.tostring(count) + "\n"
    infoTable.cell_set_text(0, 0, str.trim(tableText))

This script works as follows:

• The Signal enum defines five possible states, each with a descriptive title
• A map<Signal, float> stores running counts for each state, using enum members as keys
• On the first bar, the map is initialized with all five keys set to zero, establishing the insertion order
• On every bar, a switch expression determines the current signal state from the EMA and percent rank calculations
• The counter for that state is incremented in the map
• On the last bar, the script iterates through the map and builds a display string using str.tostring() on each enum key

The signalCounters map can hold at most six key-value pairs (five enum members plus na), giving you a predictable, bounded data structure.

Multi-Oscillator Strategy

This example builds a complete oscillator selection system where the user picks an oscillator type from a dropdown, and the script calculates and displays the selected indicator with overbought and oversold levels:

//@version=6
indicator("Multi-Oscillator Strategy")

//@enum An enumeration of oscillator choices with descriptive titles.
enum OscType
    rsi = "Relative Strength Index"
    mfi = "Money Flow Index"
    cci = "Commodity Channel Index"

OscType oscInput = input.enum(OscType.rsi, "Oscillator")
int lengthInput = input.int(14, "Length", minval = 2)
float obLevel = input.float(70, "Overbought Level")
float osLevel = input.float(30, "Oversold Level")

//@function Calculates the selected oscillator.
calcOsc(float source, simple int length, OscType selection) =>
    result = switch selection
        OscType.rsi => ta.rsi(source, length)
        OscType.mfi => ta.mfi(source, length)
        OscType.cci => ta.cci(source, length)

float oscValue = calcOsc(close, lengthInput, oscInput)

// Plot the oscillator and reference levels.
plot(oscValue, str.tostring(oscInput), color.blue, 2)
hline(obLevel, "Overbought", color.red, hline.style_dashed)
hline(osLevel, "Oversold", color.green, hline.style_dashed)

// Color the background on overbought and oversold conditions.
bgcolor(oscValue > obLevel ? color.new(color.red, 90) : na)
bgcolor(oscValue < osLevel ? color.new(color.green, 90) : na)

// Plot buy and sell arrows.
bool buySignal = ta.crossover(oscValue, osLevel)
bool sellSignal = ta.crossunder(oscValue, obLevel)
plotshape(buySignal, "Buy", shape.triangleup, location.bottom, color.green)
plotshape(sellSignal, "Sell", shape.triangledown, location.top, color.red)

The enum approach provides several advantages over the older input.string() pattern:

• The dropdown titles are defined in one place alongside the enum declaration
• The switch statement maps directly to enum members, so a typo causes a compile error instead of a silent bug
• The calcOsc() function parameter is typed as OscType, so it is impossible to pass an invalid value
• The plot title uses str.tostring(oscInput) to automatically display the selected oscillator's full name

Limitations

While enums are a powerful addition to Pine Script, there are a few constraints to be aware of.

Type Uniqueness

Each declared enum represents a completely unique type³. Even if two enums have identical field names and titles, their members are incompatible. You cannot compare members of different enums or pass a member of one enum to a function expecting another.

enum OscType
    rsi = "Relative Strength Index"

enum OscType2
    rsi = "Relative Strength Index"

// This causes a compilation error: OscType2 is not OscType.
// calcOscillator(close, 20, selection = OscType2.rsi)

This is by design. The type safety that enums provide depends on each enum being its own distinct type.

Shadowing Rules

Enum names must be unique and cannot match any built-in type names or namespaces³. For example, you cannot name an enum syminfo, ta, or polyline because those names conflict with built-in namespaces. However, capitalized variants like Syminfo or Ta are allowed, since Pine Script identifiers are case-sensitive.

// Works fine because "Syminfo" differs from the built-in "syminfo" namespace.
enum Syminfo
    abcd

// These all cause compilation errors:
// enum syminfo  -- matches built-in namespace
// enum ta       -- matches built-in namespace
// enum polyline -- matches built-in namespace

Const Qualifier

All enum fields are const values³. They are defined at compile time and cannot be modified during script execution. An input.enum() call returns a value with the input qualifier, meaning it is set once when the user configures the script's settings and does not change across bars².

No Arithmetic Operations

Enum members do not support arithmetic or ordering operations. You cannot add, subtract, or compare them with < or >. The only supported comparison operators are == and !=². If you need ordered comparisons, use a switch to map enum members to numeric values.

Conclusion

Enums bring type safety and readability to Pine Script v6 that was not possible in earlier versions¹. They replace fragile string comparisons with compiler-enforced value sets, generate clean dropdown inputs automatically, and work seamlessly with switch statements, arrays, and maps.

The key takeaways for using enums effectively are:

• Declare enums with descriptive field titles to make input.enum() dropdowns self-documenting
• Use switch statements to map enum members to calculations or actions
• Leverage map<EnumType, ValueType> for enum-keyed data structures with guaranteed bounded size
• Call str.tostring() to retrieve field titles for display in labels, tables, and log messages
• Remember that each enum is a unique type and members of different enums cannot be compared or interchanged

Whether you are building oscillator selectors, signal state trackers, or multi-mode trading systems, enums give your Pine Script code the same kind of structured, type-safe design that professional developers expect from modern programming languages.

References

¹ Pine Script Release Notes
² Pine Script v6 Language Reference
³ Pine Script User Manual
